Sintering Furnace Alignment Machine

Equipment Name：Sintering Furnace Alignment Machine；
Positioning Method：Vision Positioning；
Control System：PC-based；
Drive Method：Servo/Linear Motor；
Travel Range：
Tray Conveyor Line：Effective travel 1000 mm；
Graphite Tray Conveyor Line：Effective travel 1000 mm；
Positioning Robot: Effective travel 1100 mm；
Load Capacity：≤30 g；
Tray Loading Efficiency：
408-cell tray: ≥2600 pieces/hour；
204-cell tray: ≥2400 pieces/hour；
96-cell tray: ≥2000 pieces/hour；
Loading Accuracy：≥99%；


System Layout Reference Diagram

Floor Space: Approximately 2500 mm × 1600 mm

Equipment Height: 2100 mm

Note:

The above layout and parameters are for reference only.

On-site adjustments are required based on actual conditions.
